NFL Field Goal Analysis

A Bayesian analysis of NFL field goal data since 1999.

Tyler Pollard 2024-08-22

Data

The data is from the nflreadr package as part of the nflverse. Let $Y \in {0, 1, 2, …, n }$ be the number of field goals made in $n$ field goal attempts. Let $X \in {Regular, Clutch}$ be the situational type of kick. A clutch kick is defined as any field goal attempt where the kicking team has the opportunity to either tie or put their team in the lead with a successful field goal (ie. kicking team is losing by 0, 1, 2, or 3 points before the kick), otherwise it is regular. Let $Z \in { < 30, 30 - 39, 40 - 49, \geq 50 }$ be the binned distance of the field goal attempt, in yards.

Table1: Counts of NFL field goals made and attempted. All kicks since 1999.
Distance (Yards)
Regular
Clutch
All Kicks
Makes Attempts Makes Attempts Makes Attempts
< 30 4432 4587 2186 2261 6618 6848
30 - 39 4477 5034 2207 2506 6684 7540
40 - 49 3931 5230 1871 2563 5802 7793
>= 50 1478 2379 705 1172 2183 3551
All Distances 14318 17230 6969 8502 21287 25732

Aggregated Field Goal Analysis

We will begin with aggregating the data over the type of field goal and distance. The data $Y$ is the discrete sum of $n$ independent Bernoulli trials (0 = Miss, 1 = Make) each with success/make probability $\theta$. Therefore, the likelihood $Y|\theta$ then follows a binomial distribution with $Y|\theta \sim Binomial(n, \theta)$ and $n = 25732$ attempts. A conjugate prior for a binomial likelihood is the Beta distribution, so we select the prior $\theta \sim Beta(a, b)$ with $a=b=1$ for an uninformative prior. The posterior distribution of $\theta|Y$ can be derived by

$$ \begin{aligned} p(\theta|Y) &= \frac{f(Y|\theta)\pi(\theta)}{m(Y)} \propto f(Y|\theta)\pi(\theta) \end{aligned} $$ $$ \begin{aligned} p(\theta|Y) &\propto \left[{n \choose y}\theta^{y}(1-\theta)^{n-y}\right] \left[\frac{\Gamma(a+b)}{\Gamma(a) \Gamma(b)} \theta^{a-1} (1 - \theta)^{b-1} \right] \\ p(\theta|Y) &\propto [\theta^{Y}(1-\theta)^{n-Y}][\theta^{a-1} (1 - \theta)^{b-1}] \\ &= \theta^{(Y + a) - 1}(1-\theta)^{(n - Y + b) - 1} \\ p(\theta|Y) &\propto \theta^{A-1}(1- \theta)^{B-1} \\ \end{aligned} $$

where $A = Y + a, B = n - Y + b$. Therefore, $\theta|Y \sim Beta(Y+a,n-Y+b)$.

Posterior Distribution Plot and Prior Sensitivity Analysis

A plot of the posterior distribution for probability of making a field goal with the prior $\theta \sim Beta(1,1)$ is plotted below.

Various values of the hyperparameters $a$ and $b$ for the prior distribution were used to analyze the sensitivity of the posterior to the prior. The posterior mean, standard deviation (SD), and 95% credible interval (CI) are in the table below for the hyperparameter values $a = b = {0.5, 1, 2, 10, 100 }$. The results show that there is very little variation in the posterior for each prior, therefore, the posterior is not sensitive to the prior due to the large sample size of field goal attempts.

Table 2: Posterior summary table for varying priors
Beta(a, b)1 Mean SD2 95% CI3
0.5 0.8272 0.0024 (0.8226, 0.8318)
1 0.8272 0.0024 (0.8226, 0.8318)
2 0.8272 0.0024 (0.8226, 0.8318)
10 0.8270 0.0024 (0.8224, 0.8316)
100 0.8247 0.0024 (0.8201, 0.8293)
1 a = b
2 SD = Standard Deviation
3 CI = Credible Interval

Likelihood Verification

To verify the selected likelihood $Y|\theta \sim Binomial(n, \theta)$ is appropriate for the data, we will compare the PMF of the likelihood with the observed data $Y_{obs} = 21287$. The parameters of the likelihood were set to $n = 25732$ and $\theta = \hat{\theta} = Y/n$ to represent the sample proportion. The fit likelihood PMF has highest probability at $Y = Y_{obs}$ with very small variance when considering all possible values of $Y$ which is closely representative of the observed data. The likelihood is appropriate.

Clutch Field Goal Analysis

A hypothesis test was conducted to determine if the distribution of made fields goals given field goal attempts differ for regular vs clutch field goals. In other words, if the probability of making a regular field goal is greater than the probability of making a clutch field goal almost all of the time or never then we can say they distributions are different. Therefore, $H_0: \theta_R > \theta_C|Y_R, Y_C$ and $H_A: \theta_R \ngtr \theta_C|Y_R, Y_C$. Monte Carlo sampling was used with 10,000 samples from the posterior distribution of both $\theta_R|Y_R,Y_C$ and $\theta_C|Y_R,Y_C$ to determine $P(\theta_R > \theta_C|Y_R, Y_C)$. From the simulation, the probability of making a regular kick is greater than a clutch kick with probability $P(\theta_R > \theta_C|Y_R, Y_C) = 0.9879$ and conclude there is a difference.

Distance Field Goal Analysis

The data was further parsed into subgroups by binned field goal distance. We repeated the analysis from above, but for each subgroup to determine if the probability of making a regular field goal is higher than a clutch field goal. The hypotheses are now $H_0: \theta_{R,Z_{i}} > \theta_{C,Z_{i}}|Y_{R,Z_{i}}, Y_{C,Z_{i}}$ and $H_A: \theta_{R,Z_{i}} \ngtr \theta_{C,Z_{i}}|Y_{R,Z_{i}}, Y_{C,Z_{i}}$. Monte Carlo simulations were run again in the same fashion and the results are in Table 3 below. We can see that the distributions do not differ for each distance except for the 40 - 49 yard subgroup. The probability that the distributions are different is much higher for kicks is greater than 30 yards.

Table 3: Hypothesis probability for each binned distance
Distance (Yards) Probability
< 30 0.4543
30 - 39 0.8726
40 - 49 0.9761
>= 50 0.8718
